TYPE 3R PAINTED DOUBLE DOOR WALL MOUNT HINGED COVER ENCLOSURE WITH KEYLOCKING HANDLE
TYPE 3R PAINTED DOUBLE DOOR WALL MOUNT HINGED COVER ENCLOSURE WITH KEYLOCKING HANDLE - Image 2
TYPE 3R PAINTED DOUBLE DOOR WALL MOUNT HINGED COVER ENCLOSURE WITH KEYLOCKING HANDLE - Image 3
,

TYPE 3R PAINTED DOUBLE DOOR WALL MOUNT HINGED COVER ENCLOSURE WITH KEYLOCKING HANDLE

Construction:
  • THREE POINT LATCHING MECHANISM OPERATED BY OIL TIGHT KEYLOCKABLE HANDLE
  • STUDS PROVIDED FOR MOUNTING OPTIONAL PANEL
  • DRIP SHIELD TOP, FRONT, SIDES AND BACK PROTECT FROM FALLING RAIN, SNOW, OR SLEET
  • CODE GAUGE PAINT GRIP GALVANIZED STEEL
  • OIL RESISTANT GASKET
  • CONTINUOUS HINGE
Finish:
  • ANSI 61 GRAY POLYESTER POWDER COATING INSIDE AND OUT OVER PAINT GRIP GALVANIZED STEEL

Outdoor use to provide a degree of protection against falling rain; undamaged by the formation of ice on the enclosure.

DOWNLOAD SPEC SHEET

SKU: DWRE Categories: ,

For large quantities or custom sizes call factory
Enclosure Size HxWxDCatalog NumberWeightUPC_12Digit
48x48x8DW48488RE210 lbs
48x48x10DW484810RE220 lbs806101015642
36x36x12DW363612RE108 lbs806101034766
36x48x12DW364812RE136 lbs
42x42x12DW424212RE189 lbs
48x48x12DW484812RE232 lbs806101015659
60x60x12DW606012RE337 lbs
60x60x12DW606024RE427 lbs
48x48x14DW484814RE246 lbs
48x48x16DW484816RE258 lbs
36x36x18DW363618RE128 lbs
48x48x18DW484818RE270 lbs
48x48x24DW484824RE306 lbs
