TYPE 4X 304 STAINLESS STEEL HINGED SINGLE DOOR WITH 3 POINT LATCH & KEYLOCKING/PADLOCKING HANDLE
TYPE 4X 304 STAINLESS STEEL HINGED SINGLE DOOR WITH 3 POINT LATCH & KEYLOCKING/PADLOCKING HANDLE - Image 2
,

TYPE 4X 304 STAINLESS STEEL HINGED SINGLE DOOR WITH 3 POINT LATCH & KEYLOCKING/PADLOCKING HANDLE

Construction:
  • OIL RESISTANT GASKET
  • STAINLESS STEEL HEAVY GAUGE CONTINUOUS HINGE
  • 14 GAUGE 304 STAINLESS STEEL
  • STUDS PROVIDED FOR MOUNTING OPTIONAL BACK PANEL
  • SEAMS CONTINUOULSLY WELDED AND GROUND SMOOTH
  • 3 POINT LATCHING MECHANISM OPERATED BY KEYLOCKING / PADLOCKING L-HANDLE
Finish:
  • NUMBER 3 BRUSHED FINISH

Either indoor or outdoor use to provide a degree of protection against falling rain, splashing water, hose directed water; undamaged by the formation of ice on the enclosure; resists corrosion.

DOWNLOAD SPEC SHEET

SKU: SN4X3PT Categories: ,

For large quantities or custom sizes call factory
Enclosure Size HxWxDCatalog NumberWeightUPC_12Digit
24x24x6S24246N4X3PT48 lbs806101033288
24x16x8S24168N4X3PT40 lbs806101032397
24x20x8S24208N4X3PT46 lbs806101032731
24x24x8S24248N4X3PT53 lbs806101032748
30x20x8S30208N4X3PT55 lbs806101033240
24x30x8S24308N4X3PT63 lbs806101033233
30x24x8S30248N4X3PT63 lbs806101032755
30x30x8S30308N4X3PT81 lbs806101032762
36x24x8S36248N4X3PT73 lbs806101032779
36x30x8S36308N4X3PT87 lbs806101032786
42x36x8S42368N4X3PT127 lbs806101033271
48x36x8S48368N4X3PT127 lbs806101032793
24x20x10S242010N4X3PT51 lbs806101032809
36x24x10S362410N4X3PT79 lbs806101033257
36x30x10S363010N4X3PT93 lbs806101032816
42x30x10S423010N4X3PT108 lbs806101033264
48x36x10S483610N4X3PT135 lbs806101032823
24x24x12S242412N4X3PT62 lbs806101032830
30x24x12S302412N4X3PT73 lbs806101032847
36x30x12S363012N4X3PT99 lbs806101032854
36x36x12S363612N4X3PT114 lbs806101032861
42x36x12S423612N4X3PT142 lbs806101032878
48x36x12S483612N4X3PT143 lbs806101032885
60x36x12S603612N4X3PT173 lbs806101032892
48x36x16S483616N4X3PT160 lbs806101032908
60x36x16S603616N4X3PT191 lbs806101032915
