ELECTRICAL ENCLOSURES
| Height" | Width" | Depth" | Catalog Number | Weight | List Price | UPC_12Digit | Aluminum Panel Catalog Number | List Price | Weight | UPC_12Digit |
|---|---|---|---|---|---|---|---|---|---|---|
| 16 | 12 | 6 | A16126N4X | 9 | 806101019275 | A1612P | 1 | 806101023203 | ||
| 20 | 16 | 6 | A20166N4X | 13 | 806101019282 | A2016P | 3 | 806101023210 | ||
| 20 | 20 | 6 | A20206N4X | 16 | 806101019299 | A2020P | 4 | 806101023227 | ||
| 24 | 20 | 6 | A24206N4X | 18 | 806101019305 | A2420P | 5 | 806101023234 | ||
| 24 | 24 | 8 | A24248N4X | 22 | 806101019312 | A2424P | 6 | 806101023241 | ||
| 30 | 24 | 8 | A30248N4X | 26 | 806101019329 | A3024P | 7 | 806101023258 | ||
| 36 | 24 | 8 | A36248N4X | 29 | 806101019336 | A3624P | 9 | 806101023265 | ||
| 36 | 30 | 8 | A36308N4X | 38 | 806101019343 | A3630P | 11 | 806101023272 | ||
| 48 | 36 | 8 | A48368N4X | 56 | 806101019350 | A4836P | 19 | 806101023289 | ||
| 20 | 16 | 10 | A201610N4X | 16 | 806101019367 | A2016P | 3 | 806101023210 | ||
| 24 | 20 | 10 | A242010N4X | 22 | 806101019374 | A2420P | 5 | 806101023234 | ||
| 30 | 24 | 12 | A302412N4X | 32 | 806101019381 | A3024P | 7 | 806101023258 | ||
| 36 | 30 | 12 | A363012N4X | 44 | 806101019398 | A3630P | 11 | 806101023272 | ||
| 60 | 36 | 12 | A603612N4X | 76 | 806101019404 | A6036P | 24 | 806101023296 |
