ELECTRICAL ENCLOSURES
| Height" | Width" | Depth" | Catalog Number | Description | Weight | List Price | UPC_12Digit |
|---|---|---|---|---|---|---|---|
| 4 | 4 | 4 | 444SC | GALVANIZED SCREW COVER TYPE 1 | 2 | 806101000013 | |
| 4 | 4 | 4 | 444SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 2 | 806101000891 | |
| 4 | 4 | 4 | 444SCP | PAINTED SCREW COVER TYPE 1 | 2 | 806101003533 | |
| 4 | 4 | 4 | 444SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 2 | 806101004417 | |
| 6 | 4 | 4 | 644SC | GALVANIZED SCREW COVER TYPE 1 | 2 | 806101000020 | |
| 6 | 4 | 4 | 644SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 2 | 806101000907 | |
| 6 | 4 | 4 | 644SCP | PAINTED SCREW COVER TYPE 1 | 2 | 806101003540 | |
| 6 | 4 | 4 | 644SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 2 | 806101004424 | |
| 6 | 6 | 4 | 664SC | GALVANIZED SCREW COVER TYPE 1 | 3 | 806101000037 | |
| 6 | 6 | 4 | 664SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 3 | 806101000914 | |
| 6 | 6 | 4 | 664SCP | PAINTED SCREW COVER TYPE 1 | 3 | 806101003557 | |
| 6 | 6 | 4 | 664SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 3 | 806101004431 | |
| 8 | 6 | 4 | 864SC | GALVANIZED SCREW COVER TYPE 1 | 4 | 806101000044 | |
| 8 | 6 | 4 | 864SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 4 | 806101000921 | |
| 8 | 6 | 4 | 864SCP | PAINTED SCREW COVER TYPE 1 | 4 | 806101003564 | |
| 8 | 6 | 4 | 864SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 4 | 806101004448 | |
| 8 | 8 | 4 | 884SC | GALVANIZED SCREW COVER TYPE 1 | 5 | 806101000051 | |
| 8 | 8 | 4 | 884SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 5 | 806101000938 | |
| 8 | 8 | 4 | 884SCP | PAINTED SCREW COVER TYPE 1 | 5 | 806101003571 | |
| 8 | 8 | 4 | 884SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 5 | 806101004455 | |
| 10 | 10 | 4 | 10104SC | GALVANIZED SCREW COVER TYPE 1 | 7 | 806101000082 | |
| 10 | 10 | 4 | 10104SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 7 | 806101000969 | |
| 10 | 10 | 4 | 10104SCP | PAINTED SCREW COVER TYPE 1 | 7 | 806101003601 | |
| 10 | 10 | 4 | 10104SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 7 | 806101004486 | |
| 10 | 6 | 4 | 1064SC | GALVANIZED SCREW COVER TYPE 1 | 5 | 806101000068 | |
| 10 | 6 | 4 | 1064SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 5 | 806101000945 | |
| 10 | 6 | 4 | 1064SCP | PAINTED SCREW COVER TYPE 1 | 5 | 806101003588 | |
| 10 | 6 | 4 | 1064SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 5 | 806101004462 | |
| 10 | 8 | 4 | 1084SC | GALVANIZED SCREW COVER TYPE 1 | 5 | 806101000075 | |
| 10 | 8 | 4 | 1084SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 5 | 806101000952 | |
| 10 | 8 | 4 | 1084SCP | PAINTED SCREW COVER TYPE 1 | 5 | 806101003595 | |
| 10 | 8 | 4 | 1084SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 5 | 806101004479 | |
| 12 | 10 | 4 | 12104SC | GALVANIZED SCREW COVER TYPE 1 | 7 | 806101000112 | |
| 12 | 10 | 4 | 12104SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 7 | 806101000990 | |
| 12 | 10 | 4 | 12104SCP | PAINTED SCREW COVER TYPE 1 | 7 | 806101003632 | |
| 12 | 10 | 4 | 12104SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 7 | 806101004516 | |
| 12 | 12 | 4 | 12124SC | GALVANIZED SCREW COVER TYPE 1 | 9 | 806101000129 | |
| 12 | 12 | 4 | 12124SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 9 | 806101001003 | |
| 12 | 12 | 4 | 12124SCP | PAINTED SCREW COVER TYPE 1 | 9 | 806101003649 | |
| 12 | 12 | 4 | 12124SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 9 | 806101004523 | |
| 12 | 6 | 4 | 1264SC | GALVANIZED SCREW COVER TYPE 1 | 6 | 806101000099 | |
| 12 | 6 | 4 | 1264SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 6 | 806101000976 | |
| 12 | 6 | 4 | 1264SCP | PAINTED SCREW COVER TYPE 1 | 6 | 806101003618 | |
| 12 | 6 | 4 | 1264SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 6 | 806101004493 | |
| 12 | 8 | 4 | 1284SC | GALVANIZED SCREW COVER TYPE 1 | 6 | 806101000105 | |
| 12 | 8 | 4 | 1284SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 6 | 806101000983 | |
| 12 | 8 | 4 | 1284SCP | PAINTED SCREW COVER TYPE 1 | 6 | 806101003625 | |
| 12 | 8 | 4 | 1284SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 6 | 806101004509 | |
| 15 | 12 | 4 | 15124SC | GALVANIZED SCREW COVER TYPE 1 | 11 | 806101000136 | |
| 15 | 12 | 4 | 15124SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 11 | 806101001010 | |
| 15 | 12 | 4 | 15124SCP | PAINTED SCREW COVER TYPE 1 | 11 | 806101003656 | |
| 15 | 12 | 4 | 15124SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 11 | 806101004530 | |
| 15 | 15 | 4 | 15154SC | GALVANIZED SCREW COVER TYPE 1 | 14 | 806101000143 | |
| 15 | 15 | 4 | 15154SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 14 | 806101001027 | |
| 15 | 15 | 4 | 15154SCP | PAINTED SCREW COVER TYPE 1 | 14 | 806101003663 | |
| 15 | 15 | 4 | 15154SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 14 | 806101004547 | |
| 18 | 12 | 4 | 18124SC | GALVANIZED SCREW COVER TYPE 1 | 13 | 806101000150 | |
| 18 | 12 | 4 | 18124SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 13 | 806101001034 | |
| 18 | 12 | 4 | 18124SCP | PAINTED SCREW COVER TYPE 1 | 13 | 806101003670 | |
| 18 | 12 | 4 | 18124SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 13 | 806101004554 | |
| 18 | 15 | 4 | 18154SC | GALVANIZED SCREW COVER TYPE 1 | 16 | 806101000167 | |
| 18 | 15 | 4 | 18154SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 16 | 806101001041 | |
| 18 | 15 | 4 | 18154SCP | PAINTED SCREW COVER TYPE 1 | 16 | 806101003687 | |
| 18 | 15 | 4 | 18154SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 16 | 806101004561 | |
| 18 | 18 | 4 | 18184SC | GALVANIZED SCREW COVER TYPE 1 | 17 | 806101000174 | |
| 18 | 18 | 4 | 18184SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 17 | 806101001058 | |
| 18 | 18 | 4 | 18184SCP | PAINTED SCREW COVER TYPE 1 | 17 | 806101003694 | |
| 18 | 18 | 4 | 18184SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 17 | 806101004578 | |
| 24 | 12 | 4 | 24124SC | GALVANIZED SCREW COVER TYPE 1 | 15 | 806101000181 | |
| 24 | 12 | 4 | 24124SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 15 | 806101001065 | |
| 24 | 12 | 4 | 24124SCP | PAINTED SCREW COVER TYPE 1 | 15 | 806101003700 | |
| 24 | 12 | 4 | 24124SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 15 | 806101004585 | |
| 24 | 18 | 4 | 24184SC | GALVANIZED SCREW COVER TYPE 1 | 23 | 806101000198 | |
| 24 | 18 | 4 | 24184SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 23 | 806101001072 | |
| 24 | 18 | 4 | 24184SCP | PAINTED SCREW COVER TYPE 1 | 23 | 806101003717 | |
| 24 | 18 | 4 | 24184SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 23 | 806101004592 | |
| 24 | 24 | 4 | 24244SC | GALVANIZED SCREW COVER TYPE 1 | 35 | 806101000204 | |
| 24 | 24 | 4 | 24244SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 35 | 806101001089 | |
| 24 | 24 | 4 | 24244SCP | PAINTED SCREW COVER TYPE 1 | 35 | 806101003724 | |
| 24 | 24 | 4 | 24244SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 35 | 806101004608 | |
| 30 | 24 | 4 | 30244SC | GALVANIZED SCREW COVER TYPE 1 | 43 | 806101000211 | |
| 30 | 24 | 4 | 30244SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 43 | 806101001096 | |
| 30 | 24 | 4 | 30244SCP | PAINTED SCREW COVER TYPE 1 | 43 | 806101003731 | |
| 30 | 24 | 4 | 30244SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 43 | 806101004615 | |
| 36 | 24 | 4 | 36244SC | GALVANIZED SCREW COVER TYPE 1 | 51 | 806101000228 | |
| 36 | 24 | 4 | 36244SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 51 | 806101001102 | |
| 36 | 24 | 4 | 36244SCP | PAINTED SCREW COVER TYPE 1 | 51 | 806101003748 | |
| 36 | 24 | 4 | 36244SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 51 | 806101004622 | |
| 6 | 6 | 6 | 666SC | GALVANIZED SCREW COVER TYPE 1 | 4 | 806101000235 | |
| 6 | 6 | 6 | 666SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 4 | 806101001119 | |
| 6 | 6 | 6 | 666SCP | PAINTED SCREW COVER TYPE 1 | 4 | 806101003755 | |
| 6 | 6 | 6 | 666SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 4 | 806101004639 | |
| 8 | 6 | 6 | 866SC | GALVANIZED SCREW COVER TYPE 1 | 5 | 806101000242 | |
| 8 | 6 | 6 | 866SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 5 | 806101001126 | |
| 8 | 6 | 6 | 866SCP | PAINTED SCREW COVER TYPE 1 | 5 | 806101003762 | |
| 8 | 6 | 6 | 866SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 5 | 806101004646 | |
| 8 | 8 | 6 | 886SC | GALVANIZED SCREW COVER TYPE 1 | 6 | 806101000259 | |
| 8 | 8 | 6 | 886SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 6 | 806101001133 | |
| 8 | 8 | 6 | 886SCP | PAINTED SCREW COVER TYPE 1 | 6 | 806101003779 | |
| 8 | 8 | 6 | 886SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 6 | 806101004653 | |
| 10 | 10 | 6 | 10106SC | GALVANIZED SCREW COVER TYPE 1 | 9 | 806101000273 | |
| 10 | 10 | 6 | 10106SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 9 | 806101001157 | |
| 10 | 10 | 6 | 10106SCP | PAINTED SCREW COVER TYPE 1 | 9 | 806101003793 | |
| 10 | 10 | 6 | 10106SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 9 | 806101004677 | |
| 10 | 8 | 6 | 1086SC | GALVANIZED SCREW COVER TYPE 1 | 7 | 806101000266 | |
| 10 | 8 | 6 | 1086SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 7 | 806101001140 | |
| 10 | 8 | 6 | 1086SCP | PAINTED SCREW COVER TYPE 1 | 7 | 806101003786 | |
| 10 | 8 | 6 | 1086SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 7 | 806101004660 | |
| 12 | 10 | 6 | 12106SC | GALVANIZED SCREW COVER TYPE 1 | 10 | 806101000297 | |
| 12 | 10 | 6 | 12106SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 10 | 806101001171 | |
| 12 | 10 | 6 | 12106SCP | PAINTED SCREW COVER TYPE 1 | 10 | 806101003816 | |
| 12 | 10 | 6 | 12106SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 10 | 806101004691 | |
| 12 | 12 | 6 | 12126SC | GALVANIZED SCREW COVER TYPE 1 | 11 | 806101000303 | |
| 12 | 12 | 6 | 12126SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 11 | 806101001188 | |
| 12 | 12 | 6 | 12126SCP | PAINTED SCREW COVER TYPE 1 | 11 | 806101003823 | |
| 12 | 12 | 6 | 12126SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 11 | 806101004707 | |
| 12 | 8 | 6 | 1286SC | GALVANIZED SCREW COVER TYPE 1 | 9 | 806101000280 | |
| 12 | 8 | 6 | 1286SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 9 | 806101001164 | |
| 12 | 8 | 6 | 1286SCP | PAINTED SCREW COVER TYPE 1 | 9 | 806101003809 | |
| 12 | 8 | 6 | 1286SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 9 | 806101004684 | |
| 15 | 12 | 6 | 15126SC | GALVANIZED SCREW COVER TYPE 1 | 13 | 806101000310 | |
| 15 | 12 | 6 | 15126SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 13 | 806101001195 | |
| 15 | 12 | 6 | 15126SCP | PAINTED SCREW COVER TYPE 1 | 13 | 806101003830 | |
| 15 | 12 | 6 | 15126SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 13 | 806101004714 | |
| 15 | 15 | 6 | 15156SC | GALVANIZED SCREW COVER TYPE 1 | 16 | 806101000327 | |
| 15 | 15 | 6 | 15156SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 16 | 806101001201 | |
| 15 | 15 | 6 | 15156SCP | PAINTED SCREW COVER TYPE 1 | 16 | 806101003847 | |
| 15 | 15 | 6 | 15156SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 16 | 806101004721 | |
| 18 | 12 | 6 | 18126SC | GALVANIZED SCREW COVER TYPE 1 | 16 | 806101000334 | |
| 18 | 12 | 6 | 18126SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 16 | 806101001218 | |
| 18 | 12 | 6 | 18126SCP | PAINTED SCREW COVER TYPE 1 | 16 | 806101003854 | |
| 18 | 12 | 6 | 18126SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 16 | 806101004738 | |
| 18 | 15 | 6 | 18156SC | GALVANIZED SCREW COVER TYPE 1 | 17 | 806101000341 | |
| 18 | 15 | 6 | 18156SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 17 | 806101001225 | |
| 18 | 15 | 6 | 18156SCP | PAINTED SCREW COVER TYPE 1 | 17 | 806101003861 | |
| 18 | 15 | 6 | 18156SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 17 | 806101004745 | |
| 18 | 18 | 6 | 18186SC | GALVANIZED SCREW COVER TYPE 1 | 20 | 806101000358 | |
| 18 | 18 | 6 | 18186SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 20 | 806101001232 | |
| 18 | 18 | 6 | 18186SCP | PAINTED SCREW COVER TYPE 1 | 20 | 806101003878 | |
| 18 | 18 | 6 | 18186SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 20 | 806101004752 | |
| 24 | 12 | 6 | 24126SC | GALVANIZED SCREW COVER TYPE 1 | 21 | 806101000365 | |
| 24 | 12 | 6 | 24126SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 21 | 806101001249 | |
| 24 | 12 | 6 | 24126SCP | PAINTED SCREW COVER TYPE 1 | 21 | 806101003885 | |
| 24 | 12 | 6 | 24126SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 21 | 806101004769 | |
| 24 | 18 | 6 | 24186SC | GALVANIZED SCREW COVER TYPE 1 | 26 | 806101000372 | |
| 24 | 18 | 6 | 24186SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 26 | 806101001256 | |
| 24 | 18 | 6 | 24186SCP | PAINTED SCREW COVER TYPE 1 | 26 | 806101003892 | |
| 24 | 18 | 6 | 24186SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 26 | 806101004776 | |
| 24 | 24 | 6 | 24246SC | GALVANIZED SCREW COVER TYPE 1 | 39 | 806101000389 | |
| 24 | 24 | 6 | 24246SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 39 | 806101001263 | |
| 24 | 24 | 6 | 24246SCP | PAINTED SCREW COVER TYPE 1 | 39 | 806101003908 | |
| 24 | 24 | 6 | 24246SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 39 | 806101004783 | |
| 30 | 24 | 6 | 30246SC | GALVANIZED SCREW COVER TYPE 1 | 48 | 806101000396 | |
| 30 | 24 | 6 | 30246SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 48 | 806101001270 | |
| 30 | 24 | 6 | 30246SCP | PAINTED SCREW COVER TYPE 1 | 48 | 806101003915 | |
| 30 | 24 | 6 | 30246SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 48 | 806101004790 | |
| 30 | 30 | 6 | 30306SC | GALVANIZED SCREW COVER TYPE 1 | 81 | 806101000402 | |
| 30 | 30 | 6 | 30306SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 81 | 806101001287 | |
| 30 | 30 | 6 | 30306SCP | PAINTED SCREW COVER TYPE 1 | 81 | 806101003922 | |
| 30 | 30 | 6 | 30306SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 81 | 806101004806 | |
| 36 | 24 | 6 | 36246SC | GALVANIZED SCREW COVER TYPE 1 | 56 | 806101000419 | |
| 36 | 24 | 6 | 36246SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 56 | 806101001294 | |
| 36 | 24 | 6 | 36246SCP | PAINTED SCREW COVER TYPE 1 | 56 | 806101003939 | |
| 36 | 24 | 6 | 36246SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 56 | 806101004813 | |
| 36 | 30 | 6 | 36306SC | GALVANIZED SCREW COVER TYPE 1 | 94 | 806101000426 | |
| 36 | 30 | 6 | 36306SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 94 | 806101001300 | |
| 36 | 30 | 6 | 36306SCP | PAINTED SCREW COVER TYPE 1 | 94 | 806101003946 | |
| 36 | 30 | 6 | 36306SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 94 | 806101004820 | |
| 36 | 36 | 6 | 36366SC | GALVANIZED SCREW COVER TYPE 1 | 110 | 806101000433 | |
| 36 | 36 | 6 | 36366SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 110 | 806101001317 | |
| 36 | 36 | 6 | 36366SCP | PAINTED SCREW COVER TYPE 1 | 110 | 806101003953 | |
| 36 | 36 | 6 | 36366SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 110 | 806101004837 | |
| 48 | 24 | 6 | 48246SC | GALVANIZED SCREW COVER TYPE 1 | 101 | 806101000440 | |
| 48 | 24 | 6 | 48246SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 101 | 806101001324 | |
| 48 | 24 | 6 | 48246SCP | PAINTED SCREW COVER TYPE 1 | 101 | 806101003960 | |
| 48 | 24 | 6 | 48246SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 101 | 806101004844 | |
| 48 | 36 | 6 | 48366SC | GALVANIZED SCREW COVER TYPE 1 | 128 | 806101000457 | |
| 48 | 36 | 6 | 48366SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 128 | 806101001331 | |
| 48 | 36 | 6 | 48366SCP | PAINTED SCREW COVER TYPE 1 | 128 | 806101003977 | |
| 48 | 36 | 6 | 48366SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 128 | 806101004851 | |
| 48 | 48 | 6 | 48486SC | GALVANIZED SCREW COVER TYPE 1 | 234 | 806101000464 | |
| 48 | 48 | 6 | 48486SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 234 | 806101001348 | |
| 48 | 48 | 6 | 48486SCP | PAINTED SCREW COVER TYPE 1 | 234 | 806101003984 | |
| 48 | 48 | 6 | 48486SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 234 | 806101004868 | |
| 8 | 8 | 8 | 888SC | GALVANIZED SCREW COVER TYPE 1 | 7 | 806101000471 | |
| 8 | 8 | 8 | 888SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 7 | 806101001355 | |
| 8 | 8 | 8 | 888SCP | PAINTED SCREW COVER TYPE 1 | 7 | 806101003991 | |
| 8 | 8 | 8 | 888SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 7 | 806101004875 | |
| 10 | 10 | 8 | 10108SC | GALVANIZED SCREW COVER TYPE 1 | 10 | 806101000488 | |
| 10 | 10 | 8 | 10108SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 10 | 806101001362 | |
| 10 | 10 | 8 | 10108SCP | PAINTED SCREW COVER TYPE 1 | 10 | 806101004004 | |
| 10 | 10 | 8 | 10108SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 10 | 806101004882 | |
| 12 | 12 | 8 | 12128SC | GALVANIZED SCREW COVER TYPE 1 | 12 | 806101000495 | |
| 12 | 12 | 8 | 12128SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 12 | 806101001379 | |
| 12 | 12 | 8 | 12128SCP | PAINTED SCREW COVER TYPE 1 | 12 | 806101004011 | |
| 12 | 12 | 8 | 12128SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 12 | 806101004899 | |
| 15 | 12 | 8 | 15128SC | GALVANIZED SCREW COVER TYPE 1 | 15 | 806101000501 | |
| 15 | 12 | 8 | 15128SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 15 | 806101001386 | |
| 15 | 12 | 8 | 15128SCP | PAINTED SCREW COVER TYPE 1 | 15 | 806101004028 | |
| 15 | 12 | 8 | 15128SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 15 | 806101004905 | |
| 15 | 15 | 8 | 15158SC | GALVANIZED SCREW COVER TYPE 1 | 17 | 806101000518 | |
| 15 | 15 | 8 | 15158SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 17 | 806101001393 | |
| 15 | 15 | 8 | 15158SCP | PAINTED SCREW COVER TYPE 1 | 17 | 806101004035 | |
| 15 | 15 | 8 | 15158SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 17 | 806101004912 | |
| 18 | 12 | 8 | 18128SC | GALVANIZED SCREW COVER TYPE 1 | 17 | 806101000525 | |
| 18 | 12 | 8 | 18128SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 17 | 806101001409 | |
| 18 | 12 | 8 | 18128SCP | PAINTED SCREW COVER TYPE 1 | 17 | 806101004042 | |
| 18 | 12 | 8 | 18128SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 17 | 806101004929 | |
| 18 | 15 | 8 | 18158SC | GALVANIZED SCREW COVER TYPE 1 | 20 | 806101000532 | |
| 18 | 15 | 8 | 18158SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 20 | 806101001416 | |
| 18 | 15 | 8 | 18158SCP | PAINTED SCREW COVER TYPE 1 | 20 | 806101004059 | |
| 18 | 15 | 8 | 18158SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 20 | 806101004936 | |
| 18 | 18 | 8 | 18188SC | GALVANIZED SCREW COVER TYPE 1 | 23 | 806101000549 | |
| 18 | 18 | 8 | 18188SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 23 | 806101001423 | |
| 18 | 18 | 8 | 18188SCP | PAINTED SCREW COVER TYPE 1 | 23 | 806101004066 | |
| 18 | 18 | 8 | 18188SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 23 | 806101004943 | |
| 24 | 12 | 8 | 24128SC | GALVANIZED SCREW COVER TYPE 1 | 23 | 806101000556 | |
| 24 | 12 | 8 | 24128SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 23 | 806101001430 | |
| 24 | 12 | 8 | 24128SCP | PAINTED SCREW COVER TYPE 1 | 23 | 806101004073 | |
| 24 | 12 | 8 | 24128SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 23 | 806101004950 | |
| 24 | 18 | 8 | 24188SC | GALVANIZED SCREW COVER TYPE 1 | 29 | 806101000563 | |
| 24 | 18 | 8 | 24188SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 29 | 806101001447 | |
| 24 | 18 | 8 | 24188SCP | PAINTED SCREW COVER TYPE 1 | 29 | 806101004080 | |
| 24 | 18 | 8 | 24188SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 29 | 806101004967 | |
| 24 | 24 | 8 | 24248SC | GALVANIZED SCREW COVER TYPE 1 | 42 | 806101000570 | |
| 24 | 24 | 8 | 24248SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 42 | 806101001454 | |
| 24 | 24 | 8 | 24248SCP | PAINTED SCREW COVER TYPE 1 | 42 | 806101004097 | |
| 24 | 24 | 8 | 24248SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 42 | 806101004974 | |
| 30 | 24 | 8 | 30248SC | GALVANIZED SCREW COVER TYPE 1 | 51 | 806101000587 | |
| 30 | 24 | 8 | 30248SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 51 | 806101001461 | |
| 30 | 24 | 8 | 30248SCP | PAINTED SCREW COVER TYPE 1 | 51 | 806101004103 | |
| 30 | 24 | 8 | 30248SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 51 | 806101004981 | |
| 30 | 30 | 8 | 30308SC | GALVANIZED SCREW COVER TYPE 1 | 88 | 806101000594 | |
| 30 | 30 | 8 | 30308SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 88 | 806101001478 | |
| 30 | 30 | 8 | 30308SCP | PAINTED SCREW COVER TYPE 1 | 88 | 806101004110 | |
| 30 | 30 | 8 | 30308SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 88 | 806101004998 | |
| 36 | 24 | 8 | 36248SC | GALVANIZED SCREW COVER TYPE 1 | 60 | 806101000600 | |
| 36 | 24 | 8 | 36248SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 60 | 806101029083 | |
| 36 | 24 | 8 | 36248SCP | PAINTED SCREW COVER TYPE 1 | 60 | 806101004127 | |
| 36 | 24 | 8 | 36248SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 60 | 806101029090 | |
| 36 | 30 | 8 | 36308SC | GALVANIZED SCREW COVER TYPE 1 | 102 | 806101000617 | |
| 36 | 30 | 8 | 36308SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 102 | 806101001492 | |
| 36 | 30 | 8 | 36308SCP | PAINTED SCREW COVER TYPE 1 | 102 | 806101004134 | |
| 36 | 30 | 8 | 36308SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 102 | 806101005018 | |
| 36 | 36 | 8 | 36368SC | GALVANIZED SCREW COVER TYPE 1 | 119 | 806101000624 | |
| 36 | 36 | 8 | 36368SCP | PAINTED SCREW COVER TYPE 1 | 119 | 806101004141 | |
| 48 | 24 | 8 | 48248SC | GALVANIZED SCREW COVER TYPE 1 | 110 | 806101000631 | |
| 48 | 24 | 8 | 48248SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 110 | 806101001515 | |
| 48 | 24 | 8 | 48248SCP | PAINTED SCREW COVER TYPE 1 | 110 | 806101004158 | |
| 48 | 24 | 8 | 48248SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 110 | 806101005032 | |
| 48 | 36 | 8 | 48368SC | GALVANIZED SCREW COVER TYPE 1 | 159 | 806101000648 | |
| 48 | 36 | 8 | 48368SCP | PAINTED SCREW COVER TYPE 1 | 159 | 806101004165 | |
| 48 | 48 | 8 | 48488SC | GALVANIZED SCREW COVER TYPE 1 | 249 | 806101000655 | |
| 48 | 48 | 8 | 48488SCP | PAINTED SCREW COVER TYPE 1 | 249 | 806101004172 | |
| 12 | 12 | 10 | 121210SC | GALVANIZED SCREW COVER TYPE 1 | 14 | 806101000662 | |
| 12 | 12 | 10 | 121210SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 14 | 806101001546 | |
| 12 | 12 | 10 | 121210SCP | PAINTED SCREW COVER TYPE 1 | 14 | 806101004189 | |
| 12 | 12 | 10 | 121210SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 14 | 806101005063 | |
| 18 | 12 | 10 | 181210SC | GALVANIZED SCREW COVER TYPE 1 | 19 | 806101000679 | |
| 18 | 12 | 10 | 181210SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 19 | 806101001553 | |
| 18 | 12 | 10 | 181210SCP | PAINTED SCREW COVER TYPE 1 | 19 | 806101004196 | |
| 18 | 12 | 10 | 181210SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 19 | 806101005070 | |
| 18 | 18 | 10 | 181810SC | GALVANIZED SCREW COVER TYPE 1 | 25 | 806101000686 | |
| 18 | 18 | 10 | 181810SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 25 | 806101001560 | |
| 18 | 18 | 10 | 181810SCP | PAINTED SCREW COVER TYPE 1 | 25 | 806101004202 | |
| 18 | 18 | 10 | 181810SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 25 | 806101005087 | |
| 24 | 18 | 10 | 241810SC | GALVANIZED SCREW COVER TYPE 1 | 31 | 806101000693 | |
| 24 | 18 | 10 | 241810SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 31 | 806101001577 | |
| 24 | 18 | 10 | 241810SCP | PAINTED SCREW COVER TYPE 1 | 31 | 806101004219 | |
| 24 | 18 | 10 | 241810SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 31 | 806101005094 | |
| 24 | 24 | 10 | 242410SC | GALVANIZED SCREW COVER TYPE 1 | 48 | 806101000709 | |
| 24 | 24 | 10 | 242410SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 48 | 806101001584 | |
| 24 | 24 | 10 | 242410SCP | PAINTED SCREW COVER TYPE 1 | 48 | 806101004226 | |
| 24 | 24 | 10 | 242410SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 48 | 806101005100 | |
| 30 | 24 | 10 | 302410SC | GALVANIZED SCREW COVER TYPE 1 | 56 | 806101000723 | |
| 30 | 24 | 10 | 302410SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 56 | 806101001607 | |
| 30 | 24 | 10 | 302410SCP | PAINTED SCREW COVER TYPE 1 | 56 | 806101004240 | |
| 30 | 24 | 10 | 302410SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 56 | 806101005124 | |
| 30 | 30 | 10 | 303010SC | GALVANIZED SCREW COVER TYPE 1 | 96 | 806101000716 | |
| 30 | 30 | 10 | 303010SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 96 | 806101001591 | |
| 30 | 30 | 10 | 303010SCP | PAINTED SCREW COVER TYPE 1 | 96 | 806101004233 | |
| 30 | 30 | 10 | 303010SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 96 | 806101005117 | |
| 36 | 24 | 10 | 362410SC | GALVANIZED SCREW COVER TYPE 1 | 67 | 806101000730 | |
| 36 | 24 | 10 | 362410SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 67 | 806101001614 | |
| 36 | 24 | 10 | 362410SCP | PAINTED SCREW COVER TYPE 1 | 67 | 806101004257 | |
| 36 | 24 | 10 | 362410SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 67 | 806101005131 | |
| 36 | 30 | 10 | 363010SC | GALVANIZED SCREW COVER TYPE 1 | 111 | 806101000747 | |
| 36 | 30 | 10 | 363010SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 111 | 806101001621 | |
| 36 | 30 | 10 | 363010SCP | PAINTED SCREW COVER TYPE 1 | 111 | 806101004264 | |
| 36 | 30 | 10 | 363010SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 111 | 806101005148 | |
| 36 | 36 | 10 | 363610SC | GALVANIZED SCREW COVER TYPE 1 | 128 | 806101000754 | |
| 36 | 36 | 10 | 363610SCP | PAINTED SCREW COVER TYPE 1 | 128 | 806101004271 | |
| 48 | 36 | 10 | 483610SC | GALVANIZED SCREW COVER TYPE 1 | 171 | 806101000761 | |
| 48 | 36 | 10 | 483610SCP | PAINTED SCREW COVER TYPE 1 | 171 | 806101004288 | |
| 48 | 48 | 10 | 484810SC | GALVANIZED SCREW COVER TYPE 1 | 265 | 806101000778 | |
| 48 | 48 | 10 | 484810SCP | PAINTED SCREW COVER TYPE 1 | 265 | 806101004295 | |
| 12 | 12 | 12 | 121212SC | GALVANIZED SCREW COVER TYPE 1 | 16 | 806101000785 | |
| 12 | 12 | 12 | 121212SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 16 | 806101001669 | |
| 12 | 12 | 12 | 121212SCP | PAINTED SCREW COVER TYPE 1 | 16 | 806101004301 | |
| 12 | 12 | 12 | 121212SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 16 | 806101005186 | |
| 18 | 12 | 12 | 181212SC | GALVANIZED SCREW COVER TYPE 1 | 21 | 806101000792 | |
| 18 | 12 | 12 | 181212SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 21 | 806101001676 | |
| 18 | 12 | 12 | 181212SCP | PAINTED SCREW COVER TYPE 1 | 21 | 806101004318 | |
| 18 | 12 | 12 | 181212SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 21 | 806101005193 | |
| 18 | 18 | 12 | 181812SC | GALVANIZED SCREW COVER TYPE 1 | 28 | 806101000808 | |
| 18 | 18 | 12 | 181812SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 28 | 806101001683 | |
| 18 | 18 | 12 | 181812SCP | PAINTED SCREW COVER TYPE 1 | 28 | 806101004325 | |
| 18 | 18 | 12 | 181812SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 28 | 806101005209 | |
| 24 | 12 | 12 | 241212SC | GALVANIZED SCREW COVER TYPE 1 | 27 | 806101000815 | |
| 24 | 12 | 12 | 241212SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 27 | 806101001690 | |
| 24 | 12 | 12 | 241212SCP | PAINTED SCREW COVER TYPE 1 | 27 | 806101004332 | |
| 24 | 12 | 12 | 241212SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 27 | 806101005216 | |
| 24 | 18 | 12 | 241812SC | GALVANIZED SCREW COVER TYPE 1 | 34 | 806101000822 | |
| 24 | 18 | 12 | 241812SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 34 | 806101001706 | |
| 24 | 18 | 12 | 241812SCP | PAINTED SCREW COVER TYPE 1 | 34 | 806101004349 | |
| 24 | 18 | 12 | 241812SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 34 | 806101005223 | |
| 24 | 24 | 12 | 242412SC | GALVANIZED SCREW COVER TYPE 1 | 53 | 806101000839 | |
| 24 | 24 | 12 | 242412SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 53 | 806101001713 | |
| 24 | 24 | 12 | 242412SCP | PAINTED SCREW COVER TYPE 1 | 53 | 806101004356 | |
| 24 | 24 | 12 | 242412SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 53 | 806101005230 | |
| 30 | 30 | 12 | 303012SC | GALVANIZED SCREW COVER TYPE 1 | 103 | 806101000846 | |
| 30 | 30 | 12 | 303012SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 103 | 806101001720 | |
| 30 | 30 | 12 | 303012SCP | PAINTED SCREW COVER TYPE 1 | 103 | 806101004363 | |
| 30 | 30 | 12 | 303012SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 103 | 806101005247 | |
| 36 | 24 | 12 | 362412SC | GALVANIZED SCREW COVER TYPE 1 | 70 | 806101000853 | |
| 36 | 24 | 12 | 362412SCKO | GALVANIZED SCREW COVER W/KOs TYPE 1 | 70 | 806101001737 | |
| 36 | 24 | 12 | 362412SCP | PAINTED SCREW COVER TYPE 1 | 70 | 806101004370 | |
| 36 | 24 | 12 | 362412SCPKO | PAINTED SCREW COVER W/KOs TYPE 1 | 70 | 806101005254 | |
| 36 | 36 | 12 | 363612SC | GALVANIZED SCREW COVER TYPE 1 | 137 | 806101000860 | |
| 36 | 36 | 12 | 363612SCP | PAINTED SCREW COVER TYPE 1 | 137 | 806101004387 | |
| 48 | 36 | 12 | 483612SC | GALVANIZED SCREW COVER TYPE 1 | 179 | 806101000877 | |
| 48 | 36 | 12 | 483612SCP | PAINTED SCREW COVER TYPE 1 | 179 | 806101004394 | |
| 48 | 48 | 12 | 484812SC | GALVANIZED SCREW COVER TYPE 1 | 280 | 806101000884 | |
| 48 | 48 | 12 | 484812SCP | PAINTED SCREW COVER TYPE 1 | 280 | 806101004400 |
